I just busted out a project that I am really excited about. I finally got to make some really big three-dimensional letters… it is for a show celebrating labor protest history… and it is in a great old industrial building.
It is part of a show at Slater Mill Historic Site, a museum that is in the location of the first installation of the “Arkwright Method” of factory textile production in the United States. The exhibit is called The Mother Of All Strikes, focusing on the first factory labor walkout in US history, which happened at Slater Mill in 1824 when women loom operatives walked off their jobs and protested successfully for the restoration of their cut wages. It’s up till July 31st so there is lots of time to check it out — if you want to see it, contact me (secretdoorprojects@gmail) and I think it’s possible to arrange a free visit.
The show includes historical information & imagery, as well as artwork made specifically for it by Christine Ashley, Chelsea Carl, Priscilla Carrion, and Kristina Brown, and me!
I don’t have great pictures of the final installation yet, but here are some process shots and blurry phone pictures of the real thing, with more writing & good pictures to follow!
Slater Mill’s interior, with various textile machines from different eras (some still operational!):
A little chunk of a project description I wrote for a reporter this week:
The piece I made for Slater Mill, and for the anniversary of the 1824 strike, is called, straightforwardly, “Autonomía” — which translates to “Autonomy” in English. The large letters (made of cardboard and silk-screened paper) are staggered in space and take over six bays of the factory building, getting in people’s way — just a little bit! — as they walk around. From one end of the building you can see that they spell a word; from other viewpoints, the shapes of the letters are visible but it’s not quite clear how they fit together.
The idea of autonomy is the idea that everyone should have control over their own lives, projects, work, and associations — it’s a specific way of talking about freedom that is about self-determination and cooperation as well as about independence.
The word was created using a perspectival illusion, based on combining an architectural drawing with a drawing of the letterforms. The furthest-away letters are the largest, and as they come towards you they get smaller, so from a specific viewpoint they all appear to be the same size, floating in space, not subject to the rules of perspective. This was a way of breaking the ordered, regular spacing of the building’s structure, which was part of the control system that Slater & his partners imposed on their workers. The word is only legible in denial of the factory’s regularity, contradicting how objects are “supposed to” behave in space.
I wanted to connect workers’ struggles today to the struggles of workers in the past, and make it clear that the fight continues — right now, with the struggles of fast-food workers across the U.S. and here in Rhode Island for a $15-an-hour minimum wage, among many other battles. The word is in Spanish to allow it to communicate directly to Spanish-speaking museum visitors — and to remind English-speaking visitors that these struggles are happening all over the Americas and the world. (And also to make it clear that I am *not* quoting the 1824 workers, since we don’t have any first-hand quotes from their speeches or meetings in the historical record.)
Some epic process notes….!
Based on the building’s plan, and on my own measurements of vertical elements, I made a perspective drawing (here ghosted out under a couple layers of vellum) and then drew the letters of the word I wanted to build in such a way that it would fit into the museum’s space:
Here’s a detail of projecting the letters, these largest ones cut up into overlapping pieces, back in space onto the “picture plane” (a perspective-drawing concept, the plane where all the elements have a “true height” to scale) to figure out how large I would have to build them to get them to look the same height in person…
The largest letter was six feet three inches tall, the smallest was about 18 inches tall.
(Most of this drawing was made on a drafting desk with a parallel ruler, but I did have to take it to my parents’ house in Philadelphia with me when I went back for a family wedding in the middle of the crunch time… here it is on their dining room table, with the plan of Slater Mill above the perspective drawing…)
The thing I wish I’d done differently in the drawing process: I should have made the original plan at a larger scale; it should have been 1 foot to 1/4 inch instead of 1/8 inch! (or even bigger?) Then I would have had more ability to get accurate detail from the drawing instead of having to do complicated proportional translation. Luckily I had this trusty analog tool:
The proportional scale! Which I don’t use all the time, but when I do use it, I can’t think of anything that could replace it.
Drawings were scaled up and then transferred to cardboard. I got all this two-ply bike-box cardboard which was nice & rigid (thanks, bike shop pals!), and perfect for being able to create a gluing surface on the edges, by peeling off one layer of corrugation, and bending back the other layer to give the hot glue something to hold on to.
Draw letter, add a 3/8″ border, cut partway through & peel:
Cut through the middle flat layer:
Gently bend back the bottom corrugated layer, and squish the corrugations down:
Cut two-inch strips of cardboard and hot-glue them to the folded-down edges (the paper-wrapped bricks are weights to hold the whole thing in place & keep the glued parts pressed tight together while the glue cools):
If you drop your razor knife with the blade fully extended like that, don’t try to catch it! (I didn’t… but just barely)
Some complete letters stacked in a nice-looking pile…
Each letter had its height divided in four, and I made four stripes of this pink paper that Alison Nitkiewicz & I screenprinted more than two years ago…
(the Os extend a little beyond the top & bottom line of the letters, so they got a tiny stripe of another color pink added on the top…)
The biggest letters (the first ones that were done!) loaded in the van to go to the mill (and yes, the colors did look completely different in the daylight vs. in the studio lighting):
Late nite install:
Scøtt was a crucial, crucial helper in the hanging process, I really wouldn’t have gotten it done without his help… the timeframe was tight enough that we didn’t take any installation shots except this one, when we were almost done:
Jeremy Ferris took this nice picture at the opening, really showing the size & scale of the largest letters:
And here are another couple pictures I took as things were winding down:
And… just some of the smaller scraps of pink paper left over in the studio afterwards:
… and while we’re looking at letters, here are two variant proportions for the same letters from stops along the C subway line in Brooklyn.
These are different shapes, to fit a different size panel & with different street names (the first one is Nostrand Ave, the second one is Kingston-Throop Av), so the angles are all different… BUT the small tiles are the same size, and the “style guide” for how the tiles are cut and placed is the same, including the extension of the top point of the A and bottom point of the V past the bounding line for the rest of the letters.
